Units | UCS17 | UCS19 | UCS21 | UCS23 | UCS25 | UCS27 | UCS29 | UCS31 | UCS33 | |
---|---|---|---|---|---|---|---|---|---|---|
Seeding Distance | cm | 12 | 12 | 12 | 12 | 12 | 12 | 12 | 12 | 12 |
Number of Tines | Pcs | 17 | 19 | 21 | 23 | 25 | 27 | 29 | 31 | 33 |
Total Width | cm | 218 | 243 | 268 | 293 | 318 | 343 | 368 | 393 | 418 |
Working Width | cm | 200 | 225 | 250 | 275 | 300 | 325 | 350 | 375 | 400 |
Total Height | cm | 170 | 170 | 170 | 170 | 170 | 170 | 170 | 170 | 170 |
Total Length | cm | 250 | 250 | 250 | 250 | 250 | 250 | 250 | 250 | 250 |
Seed Hopper Volume | lt | 245 | 275 | 305 | 340 | 370 | 405 | 435 | 470 | 500 |
Fertilizer Hopper Volume | lt | 270 | 305 | 335 | 375 | 410 | 450 | 485 | 525 | 560 |
Seed Capacity(Wheat) | kg | 200 | 220 | 247 | 275 | 300 | 330 | 352 | 380 | 405 |
Fertilizer Capacity | kg | 260 | 295 | 328 | 365 | 402 | 435 | 475 | 510 | 548 |
Tire Dimensions | inch | 6.00 x 16 | 6.00 x 16 | 6.00 x 16 | 6.00 x 16 | 6.00 x 16 | 6.00 x 16 | 6.00 x 16 | 6.00 x 16 | 6.00 x 16 |
Weight | kg | 770 | 830 | 890 | 950 | 1010 | 1065 | 1125 | 1165 | 1210 |
Min. Motor Power | kw/hp | 45/60 | 45/60 | 45/60 | 60/80 | 60/80 | 60/80 | 75/100 | 75/100 | 75/100 |
