Disc Plough CDP

  • In conformity with the current agricultural conditions are available in 2, 3, 4, 5 and 6 disc version. Disc ploughs have an excellent performance in every type of soil by the basic principles such as soil breaking, soil raising, soil turning and soil mixing.
  • The disc ploughs are used to open the new fields and to process the stony areas. While processing, it avoids the occurrence of the big holes and the upper part of furrow's becoming muddy.
  • There is no possibility to be stopped up with grass, helves and farm fertilizer. Its special design allows to easier work in rocky and rooted areas.
Disc Plough CDP
Disc Plough CDP
  Units CDP2 CDP3 CDP4 CDP5 CDP6
Number of Disc pcs 2 3 4 5 6
Total Length cm 156 213 252 290 333
Total Width cm 111 126 142 157 172
Total Height cm 123 123 123 123 123
Working Depth cm 25 25 25 25 25
Working Width cm 66 99 132 165 198
Space of Disc cm 53 53 53 53 53
Diameter of Disc mm 660 660 660 660 660
Tractor Power hp 35-40 55-60 70-80 85-90 100-110
Total Weight kg 310 400 470 540 610
